Jack JK-T1790 - 3.4踏板开关的设定 Pedal switch setting

- 28 -
压脚自动地上升到最高位置①
4) END OF SEWING
Presser automatically goes up to
Maximum position ①.
4)缝制开始
把右侧踏板踩到3 级之后，缝制开
始
4) START OF SEWING
Sewing starts when the third step of
the right side pedal is depressed.
5)缝制结束
压脚自动地上升到最高位置①
5) END OF SEWING
Presser automatically goes up to
Maximum position ①.
＊ 左面①～③的各位置高度，可以用参数U01、U02、U03 进行变更。
Height of the respective positions of ①to③ described on the left
side can be set or changed by the parameter U01、U02、U03.
3.4 踏板开关的设定 Pedal switch setting
请根据存储器开关的设定，拧上或卸下图的螺丝。Attach or remove the screw shown in the figure according to the setting of
the memory switch.
