序
号
No.
按键·显示
Button and display
内容
Description
P 取消切刀按键
KNIFE CANCEL button
每次按键之后，变换显示落切刀 不落切刀。
Every time the button is pressed, dropping/non-dropping
knife is changed over alternately.
Q 压脚下降按键
PRESSER DOWN button
压脚下降。让压脚上升时， 请按压脚下降画面上的压脚上升
按键。
Presser can be lowered and the knife down screen is displayed.
To raise the presser, press the presser up button displayed in
the presser down screen.
R 绕线按键
BOBBIN WINER button
进行底线绕线。
Bobbin thread can be wound.
S 准备按键
READY button
进行数据输入画面和缝制画面的交换。
Press this button, data input screen and sewing screen can be
changed.
T 显示缝制物
SEWING PRODUCT display
显示缝制物的图像。
Image of sewing product is displayed.
U 显示缝制顺序
SEWUNG ORDER display
显示输入的图按数据的缝制顺序。用蓝色显示缝制中的图案数
据。
Sewing order of inputted pattern data is displayed. Pattern
data during sewing is displayed in blue color.
V 线张力设置按键
显示当前所选择的线张力值
NEEDLE THREAD TENSION
button
NEEDLE THREAD TENSION
mode display
触摸此键可以进行线张力值 1 和 2 之间的转换；
显示当前所选择的线张力值 1 或 2。
When this button is pressed, the needle thread tension mode 1
and 2can be changed.
The needle thread tension mode 1 and 2 which is being
selected is displayed.
12.2 循环缝制时 Performing cycle stitching
12.2.1 循环缝制文件命名 Cycle stitching named
在数据输入画面触摸 A 键，如图 12.1 所示。进入<连续缝制文件管理>画面，如图 12.3 所示：
Press button A
in data input screen(see figure 12.1), the <cycle stitching file management>screen is displayed(see
figure 12.3).
