Jack JK-T1790 - 5.3缝制数据一览 Sewing data list

- 45 -
5.3 缝制数据一览 Sewing data list
NO. 项目
Item
设定范围
Setting range
编辑单位
Edit unit
备考
Remarks
S01 缝制形状
Sewing shape
从缝纫机具有的 30 种的缝制形状中选择形状。
This item selects the shape from among the sewing shapes of 30
different kinds which the sewing machine has.
1 ～ 30
1～30 1 ---
S02 切布长度
Cloth cut length
设定用切布刀切断缝制品的长度。 但是， 图
案形状(S01 的形状 NO.27,28,29,30)时，为设定
缝制长度。把存储器开关数据的 切布刀数次动作功能设
定为有效，然后按照 切布刀尺寸设定的切刀尺寸数次地
切断缝制品
This item sets the length of cloth that is cut by cloth cutting knife.
However, in case of bar-tack shape (Nos.27, 28, 29and30of S01),
sewing length is set. By marking effective Functive of
plural motions of cloth cutting knife of memory switch data,make the
plural motions of knife size set in the item Cloth cutting
knife size, and the sewing product is cut.
3.0～120.0 0.1mm ---
S03 切刀槽右宽度
Knife groove width, right
设定切刀和右平行布的间隙。
This item sets the clearance between cloth cutting knife and right
parallel section
-2.00～2.00 0.05mm ---
S04 切刀槽左宽度
Knife groove width, left
设定切刀和左平行部的间隙。
This item sets the clearance between cloth cutting knife and left
parallel section.
-2.00～2.00 0.05mm ---
S05 左包边宽度
Overedging width, left
设定左平行部的包边宽度。
This item sets the overedging width of left parallel section.
0.10～5.00 0.05mm ---
