- 46 -
NO. 项目
Item
设定范围
Setting range
编辑单位
Edit unit
备考
Remarks
S06 左右形状比率
Ratio of right and left shapes
设定以切刀位置为中心的右侧形状的扩大缩小率。
This item sets enlargement/reduction ratio of right side shape
making, the knife position as the center.
50～150 1% ---
S07 平行部间距
Pitch at parallel section
设定左右平行部的缝制间距。
This item sets sewing pitch of left and right parallel sections.
0.200～
2.500
0.025mm ---
S08 第 2 加固缝长度
2nd bar-tacking length
设定前侧加固缝部的长度。
This item sets length of bar-tacking on the front side.
方型下
直线加固下 合并下
Square type, bottom Straight bar-tack, bottom
Flow, bottom
0.2～5.0 0.1mm ---
S09 第 1 加固缝长度
1st bar-tacking length
设定里侧加固缝部的长度。
This item sets length of bar-tacking on the rear side.
方型上
Square type, top
0.2～5.0 0.1mm ---
S10 右加固宽度修正
Compensation of bar-tacking width, right
对加固部的右侧外形包边缝部进行调整。
第1， 第 2 加固均被修正。
方型上 方型下 直线加固下
This item adjusts left side outer shape of bar-tacking section in
terms of overedging section. Both 1st and 2nd bar-tacking can be
compensated.
Square type, top Square type, bottom Straight bar-tack, bottom
-1.00～1.00 0.05mm ---
S11 左加固宽度修正
Compensation of bar-tacking width, left
对加固部的左侧外形包边缝部进行调整。
This item adjusts left side outer shape of bar-tacking in terms of
overedging section.
-1.00～1.00 0.05mm ---
