Jackson Conserver AXL Service Manual

DIMENSIONS
12
Jackson
65 1/2"
73 7/8"
W/ DOOR
OPEN
13"
61 7/8"
FLOOR TO C
OF WATER INLET
BACK OF MACHINE
TO C OF DRAIN
11 1/4"
56 1/8"
34"
TABLE
HEIGHT
3/4"
5"
TOP OF MACHINE
TO C OF ELEC. CON.
3 3/4"
15 1/4"
EDGE OF WATER INLET
TO SIDE OF MACHINE
4"
BACK OF CONTROL BOX
TO BACK OF MACHINE
2 3/8"
C OF WATER INLET
TO BACK OF MACHINE
SIDE OF MACHINE
TO C OF ELEC. CON.
C
STANDARD CLEARANCE BETWEEN
MACHINE AND WALL (WITH
DISHTABLE) IS 4”.
B
A
LEGEND:
A - WATER INLET (3/4” IPS)
B - ELECTRICAL CONNECTION POINT
C - DRAIN (2” IPS)
