Jackson Conserver AXL Service Manual

PERISTALTIC PUMP ASSEMBLY
19
ITEM QTY DESCRIPTION MFG. No.
1
2 Screw, 8-32 x 3/8" Phillips Flat Head 5305-011-37-07
2
1 Housing, Front 4320-111-37-08
3
1 Anko Roller 4320-111-36-70
4
1 Peri Pump Squeeze Tube 5700-111-35-29
5
4 Screw, 6-32 x 3/4" Phillips Pan Head 5305-011-37-05
6
1 Screw, 8-32 x 1/2" Phillips Flat Head 5305-011-37-06
7
1 Housing, Rear Assy 4320-111-37-09
8
1 Peri Pump Motor (14 RPM) Rinse Additive 4320-111-35-13
9
2 Peri Pump Motor (36 RPM) Detergent & Sanitizer 4320-111-35-14
* - ITEM NOT SHOWN
1
2
3
4
5
6
7
8
