Jackson Conserver AXL Service Manual

WASH MANIFOLD ASSEMBLY
30
ITEM QTY DESCRIPTION MFG No.
1
1 Tube, Wash Manifold 5700-002-00-19
2
2 O-Ring, Wash Manifold 5330-111-35-15
3
1 Lower Wash Manifold Weldment 5700-002-05-87
4
1 Upper Wash Manifold Casting 5700-031-34-82
5
2 Manifold Gasket 5700-111-35-03
6
2 Bolt, 3/8"-16 x 7/8" Long 5306-011-36-95
7
4 Lockwasher, 3/8" 5311-276-01-00
8
4 Nut, 3/8"-16. Hex 5310-276-01-00
9
1 Bolt, 3/8"-16 x 1 1/4" Long 5305-276-10-00
10
1 Bolt, 3/8"-16 x 1 3/4" Long 5306-011-36-94
11
2 Washer, 3/8", Bevel, Square, Iron 5311-011-35-36
*12
1 Bracket, Manifold Tube Positioning 5700-011-34-63
*13
1 Locknut, 1/4"-20, Hex w/ Nylon Insert 5310-374-01-00
