T
O PREPARE PUMPS FOR OPERATION
The Conserver XL dishmachine is supplied with detergent, rinse additive and sanitizer dispensing peristaltic-pumps. Locate the open
ends of the chemical tubes with the tube stiffeners and place each one in the appropriate container.
A. Red Tubing = Detergent
B. Blue Tubing = Rinse Aid
C. White Tubing = Sanitizer.
PRIMING PERIST
AL
TIC-PUMPS
Peristaltic pumps need priming when the machine is first installed or if for some reason the chemical lines have been removed and
air is allowed to enter.
CAUTION: Water must be in the sump and wash tank prior to the dispensing of chemicals. Sanitizer in concentration is
caustic and may cause damage without dilution.
1. Verify that the proper chemical tube stiffener inlet is in the proper container.
2. Use the toggle switches on the right side of control box to prime each pump. There are two (2) switches mounted by the peri-
staltic-pumps. One will prime the sanitizer pump only, and the second will prime either the detergent or rinse aid pump, depending
upon which way it is depressed.
3. To prime the pumps, hold the switch in the momentary position until chemical can be observed entering the sump.
4. Detergent is dispensed as required during the wash cycle by the cam timer. The amount of detergent may need to be increased or
decreased depending on water quality and type of detergent. It is adjusted by changing Cam 6 on the cam timer. See the timer
instructions on Page 5.
5. Rinse additive is dispensed as required into the final rinse. The amount of rinse aid may need to be adjusted depending on water
hardness and results. It can be changed by changing Cam 7 on the cam timer. See the timer instructions on Page 5
6. Chlorine based sanitizer is dispensed into the final rinse. The amount of sanitizer may need to be adjusted depending on the con-
centration and type of sanitizer used. It is adjusted by changing Cam 5 on the cam timer. See the timer instructions on Page 5.
CHEMICAL DISPENSING EQUIPMENT
3
