SECTION DESCRIPTION PAGE
Miscellaneous Parts (ES-2000 & ES-4000) 66
Door Assemblies (ES-2000) 67
Door Assemblies (ES-4000) 68
False Panel Option 69
ES-4000CDL Assembly Options 70
ES-4000CDR Assembly Options 72
Vapor Vent Option Assembly (Revision A) 74
Vapor Vent Option Assembly (Revision B) 75
SDI Option (ES-2000HHV) 76
Dispenser Assembly (Front View) 77
Solenoid Mounting Plate Assembly 78
VII. SCHEMATICS
ES-2000/ES-2000-CS (115 Volt, 60 Hz, single phase) 80
ES-2000-V (115 Volt, 60 Hz, single phase) 81
ES-2000XSP (115 Volt, 60 Hz, single phase) 82
ES-4000 (115 Volt, 60 Hz, single phase) 83
ES-4000CDL/ES-4000CDR (115 Volt, 60 Hz, single phase) 84
ES-4000XSP (115 Volt, 60 Hz, single phase) 85
TABLE OF CONTENTS
iv
