79
> Change from previous revision
AR-5
Item Part No. Qty. Description Serial Numbers/Notes
1
400404 4 Screw, 1/2-13 x 1” Hex Head
2 400408 4 Screw, 1/2-13 x 1-1/2” Hex Head
3 400418 4 Screw, 1/2-13 x 3” Hex Head
4 4123168 1 Deck Frame
5 4127478 4 Flanged Bushing
6 471214 2 Straight Grease FItting
7 4124423 1 LH Rear Cutting Height Bracket
8 4124425 1 RH Rear Cutting Height Bracket
9 4130647 1 Scraper, Roller
10 443818 2 Nut, 1/2-13 Hex Jam
11 445771 2 Nut, 1/2-13 Hex Nylon Insert
12 446152 2 Lockwasher, 1/2
13 4129614 1 RH Roller Bracket
14 4129615 1 LH Roller Bracket
15 412017 2 Screw, 5/16-18 x 3/4” Square Head
16 461383 2 Roll Pin, 3/16 x 1”
17 4123031 1 Roller
18 503378 2 Bearing Cup and Cone
19 367029 1 Locknut, 3/4-16 Hex Jam
20 3010210 2 Seal
21 4122993 1 Tube, Roller
22 4124015 1 Shaft, Roller
23 800379 12 Nut, 1/2-13 Spiralock Flange
24 4124129 2 Spacer
25 4124395 1 Front Cutting Height Bracket
