51
> Change from previous revision
AR-5
Item Part No. Qty. Description Serial Numbers/Notes
1
3002195 1 Elbow, 1/8 NPF 90°
2 326112 5 Clamp, 1-5/16 to 2-1/4” Dia Hose
3 345666 1 Clamp, 1/2” P Hose
4 337229 2 Clamp, Hose
5 5003447 AR Tube, Neoprene Cut to 33”
6 365398 1 Indicator, Air Cleaner
7 366526 2 Clamp, 1/4” to 5/8” Dia Hose
8 400188 3 Screw, 5/16-18 x 1” Hex Head
9 4134775 1 Shroud, Rear Frame
10 4120925 1 Hose, Radiator Inlet
11 4120932 1 Hose, Radiator Outlet
12 4120976 1 Hose, Air Cleaner to Engine
13 4120977 1 Hose, Shroud to Air Cleaner
14 4121020 1 Bracket, Air Cleaner
15 4134775 1 Shroud, Fan
16 4128079 1 Seal, Trim
17 4128083 1 Air Cleaner
4133818 1 • Cover, Air Cleaner
4133820 1 • Filter, Primary Air Cleaner
4133821 1 • Filter, Safety Air Cleaner
5003373 1 • Vactuator Valve
18 4128084 1 Bracket, Air Cleaner Mount
19 444718 1 Locknut, 5/16-18 Center
20 445640 2 Nut, 3/8-16 Steel Wing
21 445795 2 Nut, 5/16-18 Spiralock Flange
22 445796 4 Nut, 3/8-16 Spiralock Flange
23 452006 1 Flat Washer, 5/16
24 452008 9 Flat Washer, 3/8
25 557367 1 Reserve Tank
26 557374 1 Stay, Tank
27 358794 4 Flat Washer, 3/8
28 400264 6 Screw, 3/8-16 x 1-1/4” Hex Head
29 400262 2 Screw, 3/8-16 x 1” Hex Head
30 4136164 1 Radiator / Hydraulic Oil Cooler
550863 1 • Radiator Cap
31 446140 8 Lockwasher, 3/8
32 4133244 1 Bracket, Remote Oil Filter
33 366618 2 Grommet
To Next Page
