GB-21
GB
JACOBSEN FAIRWAY 250 Series DH
SAFETY AND OPERATORS MANUAL
7 OPERATION
7.6 MOWING
1. Lower the units with the cutting unit lift
control.
2. Ensure speed limiter is in mow position
3. Engage the cutting mechanism by pushing
on the lower half of cutting unit switch and
operating the floor mounted switch.
3. Release the parking brake and begin
driving forward.
NOTE: Always set the throttle to full for mowing,
even when the grass is heavy. When the
engine is labouring, reduce forward speed
by easing up on the FWD/REV foot pedal.
7.7 TO STOP THE ENGINE
1. Disengage power to the cutting units with
the cutting unit switch.
2. Remove foot from the FWD/REV pedal.
3. Set the parking brake.
3. Move the throttle control lever to the
SLOW position.
4. Turn the ignition key to OFF.
7.8 PUSHING THE MACHINE WITH THE
ENGINE STOPPED
1. To push, disengage the parking brake.
2. Turn screw (A) located on the underside of
the transmission pump 1 turn
counterclockwise. Set the steering wheel
so that the rear wheels are pointing
straight ahead.
3. After pushing, return screw (A) to their
previous positions.
DO NOT exceed the following speeds and distance
when moving the machine in 'Free Wheel'.
Maximum Speed: 1.5 Km/Hr (1 mph)
Maximum Distance: 2Km (1 1/4 miles)
DO NOT allow the machine to free wheel down
slopes even when unloading down ramps.
