MAINTENANCE & LUBRICATION CHARTS 6
25
6 MAINTENANCE & LUBRICATION CHARTS
6.1 GENERAL ________________________________________________________________
1. Always clean grease fittings before and after
lubrication.
2. Lubricate with grease that meets or exceeds NLGI
Grade 2 LB specifications. Apply grease with a
manual grease gun and fill slowly until grease
begins to seep out. Do not use compressed air.
3. For smooth operation of pivot points and other
friction points, apply several drops of SAE 30 oil
every 50 hours or as required.
4. Remove wheels and repack bearings once a year.
6.2 MAINTENANCE CHART_____________________________________________________
A - Add or Adjust C - Clean I - Inspect L- Lubricate R - Replace AR - As Required
* Indicates initial service for new machines.
** Or every two years whichever comes first.
*** Inspect visible hoses and tubes for leaks or oil marks.
I Pack bearings with NLGI Grade 2 (Service Class GB)
II Manual grease gun with NLGI Grade 2 (Service Class LB).
III Manual grease gun with Multipurpose lithium or moly 2 EP grease
IV Textron Turf Care And Specialty Products Hydraulic Oil - SAE 10W30
WARNING
Before you clean, adjust, or repair this equipment,
disengage all drives, lower implements to the ground,
engage parking brake, stop engine and remove key from
ignition switch to prevent injuries.
!
Recommended Service and Lubrication Intervals
Every
8-10
Hours
Every
50
Hours
Every
100
Hours
Every
250
Hours
Every
400
Hours
Every
500
Hours
Every
1000
Hours
Yearly Lubri-
cant
Type
Air Cleaner
IR
Battery Charge
I
Belt (Alternator)
I-A* I-A R
Brake
I-A* A
Cooling System
I-C-A R
Engine Oil
R* R
Engine Oil Filter
R* R
Fuel Lines and Clamps
I
Fuel Filter
R
Grease Fittings - F1
L II
Grease Fittings - F2
L II
Grease Fittings - F3
L III
Hydraulic Hoses and Tubes
I*** I
Hydraulic Oil
I-A R** IV
Hydraulic Oil FIlters
R* R-AR
Muffler and Exhaust
I
Radiator Screens
I-C/AR
Tires
I-A
Steering System
I* I-A
Wheel Bearings
L I
Wiring
I* I
To Next Page
