LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
1004391 1 Wing, L.H. Mounting Assembly
2 1004392 1 Wing, R.H. Mounting Assembly
3 4170621 1 Arm, L.H. Mounting Assembly
4 3006539 4 • Bushing 2 Per Lift Arm
5 4170622 1 Arm, R.H. Mounting Assembly
6 1004492 2 Pin, Cylinder
> 7 4140149 2 Switch, Proximity
8 3007989 2 Pin, Cylinder
9 455004 4 Flat Washer, 1”
10 1002498 2 Yoke Pivot
11 446154 8 Lockwasher, 1/2 Heavy
12 400406 8 Screw, 1/2-13 x 1-1/4” Hex Head
13 2500477 4 Machinery Bushing
14 461409 4 Roll Pin
15 1003359 1 Lift Yoke, Left Side LF-4675 Units Only
16 1003360 1 Lift Yoke, Right Side LF-4675 Units Only
17 3008432 2 Cap, Swivel Housing
18 3007798 2 Lock Pin
19 471214 15 Grease Fitting
20 446142 4 Lockwasher, 3/8 Heavy
21 400258 4 Screw, 3/8-16 x 3/4” Hex Head
22 367028 2 Clamp, Open
> 23 4138513 2 Cylinder, Wing
24 403860 4 Screw, #8-32 x 5/8” Truss Head
25 453004 4 Flat Washer, 1/4
26 446110 4 Lockwasher, #8
27 444306 4 Nut, #8-32 Hex
28 1003361 2 Lift Yoke LF-4677 Units Only
29 1004416 2 Pin, Wing
30 3007575 2 Support, Hose
31 400276 2 Screw, 3/8-16 x 2-1/2” Hex Head
32 358794 4 Flat Washer, 3/8
33 444762 7 Locknut, 7/16-18 Center
34 3009193 1 Shim, Switch
To Next Page
