103

> Change from previous revision

LF 570

Item Part No. Qty. Description Serial Numbers/Notes

4217400 1 Tube, Return Filter

See 26.1 and 29.1 for connecting

tubes

339912 1 • O-Ring, -12 ORFS

339913 1 • O-Ring, -16 ORFS

2 339999 2 Fitting, 16-16 Straight

339913 1 • O-Ring, -16 ORFS

339901 1 • O-Ring, -16 ORB

3 132704 1 Filter, Return Hydraulic See 19.1

557772 1 • Filter Element

4 4129642 1 Hose, Return Filter to Oil Cooler

5 4123166 1 Tee, 16-16-16 25 PSI Check Valve Flow arrow should point down.

339913 2 • O-Ring, -16 ORFS

339901 1 • O-Ring, -16 ORB

6 4120720 1 Radiator/Hydraulic Oil Cooler

7 4129656 1 Hose, Oil Cooler Bypass

8 340267 1 Tee, 16-16-16 Run

339913 2 • O-Ring, -16 ORFS

339901 1 • O-Ring, -16 ORB

9 4215400 1 Tube, Oil Cooler Return

See 21.1, 22.1, 23.1, and 24.1 for

connecting tubes

339908 2 • O-Ring, -4 ORFS

339909 1 • O-Ring, -6 ORFS

10 4124647 1 Hose, Return Tube

11 3008673 2 Clamp, Constant Torque Hose

12 361689 1 Fitting, -16 ORB x 1” barbed

339901 1 • O-Ring, -16 ORB

13 3005871 1 Tank, Hydraulic See 18.1
