MAINTENANCE & LUBRICATION CHARTS 7
33
7 MAINTENANC E & LUBRICATION CH ARTS
7.1 GENERAL ________________________________________________________________
1. Always clean grease fittings before and after lubrication.
2. Lubricate with grease that meets or exceeds NLGI
Grade 2 LB specifications. Apply grease with a manual
grease gun and fill slowly until grease begins to seep
out. Do not use compressed air.
3. For smooth operation of pivot points and other friction
points, apply several drops of SAE 30 oil every 50
hours or as required.
4. Remove wheels and repack bearings once a year.
7.2 MAINTENANCE CHART_____________________________________________________
A - Add or Adjust C - Clean I - Inspect L- Lubricate R - Replace AR - As Required
* Indicates initial service for new machines.
** Or Yearly whichever comes first. *** Inspect visible hoses and tubes for leaks or oil marks.
I Pack bearings with NLGI Grade 2 (Service Class GB)
II Manual grease gun with NLGI Grade 2 (Service Class LB).
III Engine Oil - See Section 5.3
IV Jacobsen Hydraulic Oil - SAE 10W30 or Greens Care 68
WARNING
Before you clean, adjust, or repair this equipment,
disengage all drives, lower implements to the ground,
engage parking brake, stop engine, and remove key from
ignition switch to prevent injuries.
Recommended Service and Lubrication Intervals
Every
8-10
Hours
Every
50
Hours
Every
100
Hours
Every
250
Hours
Every
400
Hours
Every
500
Hours
Every
1000
Hours
Yearly See
Section
Lubricant
Type
Air Cleaner
AR R 5.4
Battery Charge
I5.9
Belt
I-A* I-A R 4.7
Brake
I-A* A 4.8
Cooling System/Coolant
I-C-A R 5.15
Engine Oil
IR*R 5.2III
Engine Oil Filter
R* R 5.3
Fuel Lines and Clamps
I
Fuel Filter
R5.6
Grease Fittings - F1
L7.3II
Grease Fittings - F2
L7.3II
Grease Fittings - F3
L7.3II
Hydraulic Hoses and Tubes
I*** I 5.11
Hydraulic Oil
I-A R** 5.12 IV
Hydraulic Oil FIlters
R* R-AR 5.13
Muffler and Exhaust
I5.10
Radiator Screens
I-C/AR 5.15
Tires
I-A 5.17
Steering System
I* I-A
Wheel Bearings
L I
Wiring
I* I 5.14
To Next Page
