Jacobsen LF570 User Manual

144
A
B
P
G
T
.5 ci .5 ci .5 ci
Gear
Pump
Rear
Reel
Valve
Front
Reel
Valve
1167
psi
1167
psi
LR Reel Motor
RR Reel Motor
*
*
1167
psi
LF Reel Motor
*
1167
psi
C Reel Motor
*
1167
psi
RF Reel Motor
*
Reel
Diag.
Reel
Diag.
Strg.
Diag.
10
Micron
25 psi
Crack
Bypass
25 psi
Crack
Bypass
100
Mesh
Screen
Return
Filter
Oil
Cooler
A
B
C
D
E
F
G
H
* Reel Motor Displacement
LF-3400 .72 ci
LF-3800 1.01 ci
A
B
P
G
T
3625
psi
4350
psi
315 psi
2.81 ci
Tow
Valve
Reverse
Diag.
Forward
Diag
3150
RPM
A
B
Traction
Pump
EDC
LF 550
45.2 2WD Hydraulic Schematic
Serial No. 67978 - 2500 and Up
Serial No. 67981 - 2500 and Up
