Jacobsen LF570 User Manual

105
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
1002154 1 Gear Pump See 17.1
2 340292 4 Union, -10 ORFS x -10 ORFS Straight
339911 2 • O-Ring, -10 ORFS
3 4244263 1 Hose, Pump to Front Reel Valve
4 339990 1 Fitting, -10 ORFS x -12 ORB Straight
339911 1 • O-Ring, -10 ORFS
339900 1 • O-Ring, -12 ORB
5 365466 1 Fitting, -6 ORB Diagnostic
339897 1 • O-Ring, -6 ORB
6 363030 1 Dust Cover
7 339989 2 Fitting, -10 ORFS x -10 ORB Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
8 4217700 1 Tube, Reel Valve to Right Reel
9 4218406 4 Hose, Left and Right Reel
10 340070 8 Fitting, -10 ORFS x -10 ORB 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
11 2822503 3 Reel Motor, 5” Reel Used on LF 550, See 43.1
11 1002620 3 Reel Motor, 7” Reel Used on LF 570, See 44.1
12 4218418 1 Tube, Right to Center Reel
13 4216640 2 Hose, Center Reel
14 4218419 1 Tube, Center to Left Reel
15 4217701 1 Tube, Left Reel to Reel Valve
16 4195041 1 Valve, Reel See 19.1
17 4218100 1 Tube, Reel Valve to Filter Tube
18 4217400 1 Tube, Return Filter See 25.1
339912 1 • O-Ring, -12 ORFS
339913 1 • O-Ring, -16 ORFS
19 339972 3 Fitting, -4 ORFS x -4 ORB Straight
339908 1 • O-Ring, -4 ORFS
339896 1 • O-Ring, -4 ORB
20 4218408 2 Hose, Left and Right Motor Drain
21 4218020 1 Tube, Left Front Reel Motor Drain
22 4218021 1 Tube, Center Reel Motor Drain
23 4218022 1 Tube, Right Front Reel Motor Drain
24 4113601 1 Tube, Return Manifold See 20.1
339908 5 • O-Ring, -4 ORFS
25 4216620 1 Hose, Center Reel Drain
26 400118 3 Screw, 1/4-20 x 1”
27 3003110 3 Clamp, Double 5/8” Tube See 31.1
28 366811 3 Clamp, 3/8” Tube See 31.1
29 444708 3 Locknut, 1/4-20 Center
30 473142 5 Cable Tie, 3/16” x 14” Not Shown
31 340288 2 Union, -6 ORFS x -6 ORFS Straight
339909 2 O-Ring, -6 ORFS
