113
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4212981 1 Steering Valve See 11.1
2 1003339 1 Hose, Steering Valve to Lift Valve Steering Valve Port T, Lift Valve Port T
3 1003340 1 Hose, Steering Valve to Lift Valve Steering Valve Port E, Lift Valve Port P
4 339985 2 Fitting, 8-10 Straight
339910 1 • O-Ring, -6 ORFS
339899 1 • O-Ring, -10 ORB
5 4195081 1 Lift Valve See 19.1
6 339979 6 Fitting, 6-6 Straight
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
7 3000953 6 Disk, 0.040” Orifice
339909 1 • O-Ring, -6 ORFS
8 4240022 1 Hose, Lift Valve to Right Cylinder Lift Valve Port 1, Cylinder Rod Port
9 4240182 1 Hose, Lift Valve to Center Cylinder Lift Valve Port 2, Cylinder Rod Port
10 4240183 1 Hose, Lift Valve to Left Cylinder Lift Valve Port 3, Cylinder Rod Port
11 340061 6 Fitting, 6-6 90°
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
12 4193221 2 Cylinder, Lift See 32.1
13 4193220 1 Cylinder, Lift See 32.1
14 4240023 1 Hose, Right Cylinder to Lift Valve Lift Valve Port 8, Cylinder Base Port
15 4240024 1 Hose, Center Cylinder to Lift Valve Lift Valve Port 9, Cylinder Base Port
16 4240025 1 Hose, Left Cylinder to Lift Valve Lift Valve Port 10, Cylinder Base Port
17 108138-04 2 Clamp, Double Tube
18 409811 2 Screw, 5/16-18 x 5/8” Thread Cutting
19 473142 1 Cable Tie, 3/16 x 14” Right Cylinder Hoses
20 365466 1 Fitting, -6 ORB Diagnostic
339897 1 • O-Ring, -6 ORB
21 363030 1 Cover, Dust
To Next Page
