121
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4170623 1 Left Front Lift Arm
2 4170624 1 Right Front Lift Arm
3 4170626 1 Left Rear Lift Arm
4 4170627 1 Right Rear Lift Arm
5 4170625 1 Center Lift Arm
6 3006539 10 • Bushing 2 Per Lift Arm
7 1002498 5 Yoke, Pivot
8 3008432 5 Cap, Swivel Housing
9 4193221 2 Lift Cylinder, Left and Right Front
4194460 1 • Seal Kit
10 4193220 3 Lift Cylinder, Center and Rear
4194020 1 • Seal Kit
11 3007798 5 Lock Pin
12 3007989 5 Pin, Cylinder
13 362824 5 Spacer, Lift Arm
14 364248 5 Collar
15 455004 10 Flat Washer, 1
16 400272 5 Screw, 3/8-16 x 2-1/4” Hex Head
17 2500477 5 Machinery Bushing
18 444762 7 Locknut, 7/16-18 Center
19 461409 15 Roll Pin, 3/16x x1-3/4”
20 3009490 5 Wave Washer
21 4125831 2 Switch, Proximity
REFERENCE SW-14 and SW-16, See
48.1
22 800440 4 Screw, #4-40 x 1” Truss Head
23 308404 4 Flat Washer, #4
24 446102 4 Lockwasher, #4
25 444302 4 Nut, #4-40 Hex
26 4244650 2 Support, Hose
27 400276 2 Screw, 3/8-16 x 2-1/2” Hex Head
28 358794 4 Flat Washer, 3/8
29 1003361 5 Lift Yoke LF 570
30 1003359 2 Lift Yoke, Left Side LF 550
31 1003360 3 Lift Yoke, Right Side and Center LF 550
32 471214 15 Grease Fitting
33 453004 4 Washer, Flat
34 4176860 2 Plate, Proximity Switch
To Next Page
