123
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
------------ 1 Tray, Battery See 7.1
2 4122840 2 Headlight
4123183 1 • Bulb REFERENCE L-1 and L-2, See 48.1
3 4216680 1 Controller REFERENCE U-6, See 48.1
4 5003282 2 • Fuse, 20 Amp REFERENCE F-1 & F-2, See 48.1
5 4235060 7 Tie Strap, Push Nut Mount Mounts to weld stud on frame.
6 N/S 1 Battery REFERENCE B-1, See 48.1
7 402066 4 Screw, #8-32 x 1” Hex Head
8 445795 5 Nut, 5/16-18 Spiralock Flange
9 445796 2 Nut, 3/8-16 Spiralock Flange
10 444310 4 Nut, #10-24 Hex
11 3007777 1 Cable, Positive Battery
12 2810213 1 Cable, Negative Battery
13 444306 4 Nut, #8-32 Hex
14 4217421 1 Body Wire Harness
15 4193880 2 • Relay-SPDT With Diode REFERENCE K-10 and K-11, See 48.1
16 446118 4 Lockwasher, #10
17 403910 4 Screw, #10-24 x 1/2” Truss Head
18 361439 1 Circuit Breaker, 12V 50A REFERENCE CB-1, See 48.1
19 409804 3 Screw, #10-32 x 1/2” Thread Cutting
20 3007558 1 Clamp, Double Tube
21 400188 3 Screw, 5/16-18 x 1” Hex Head
22 5001189 1 Fuel Filter Assembly Included With Engine
2500809 1 • Fuel Filter Element
2501023 1 • Filter Cover
2501024 1 • Filter Breather Plug
2501025 1 • O-Ring
2501026 1 • Form, Mark
23 453004 4 Flat Washer, #8
24 446112 4 Lockwasher, #8 Heavy
25 4136366 4 Spacer, 3/8 x 5/16
To Next Page
