125
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
5003087 1 Frame, Reel
2 4182520 2 • Decal, Danger
3 4181863 1 • Decal, Warning
4 5003053 1 7 Blade Left Hand Reel Used on 67984
4 5003054 1 7 Blade Right Hand Reel Used on 67985
5 1004786 1 Bearing Housing
6 500534 1 • Bearing, Cup and Cone
7 336962 1 • Seal, Grease
8 471214 1 • Grease Fitting
9 471242 1 • Vent Fitting
10 3010296 2 • Pin, Motor Mounting
11 444708 2 • Locknut, 1/4-20 Center
12 458013 1 Snap Ring
13 367164 1 Spacer
14 5000415 1 Bedknife Backing
15 5003150 1 Bedknife, Low Profile Fairway Standard
15 503460 1 Bedknife, Heavy Section Optional
16 3009138 13 Screw, 1/4-20 x 1/2” Flat Head
17 315298 2 Bolt, 7/16 x 3/4”
18 4125770 1 Decal, Patent
19 445795 8 Nut, 5/16-18 Spiralock Flange
20 453009 4 Flat Washer, 5/16
21 1000480 1 Bearing Housing
2000060 1 • Housing
22 500534 1 • Bearing, Cup and Cone
23 336962 1 • Seal, Grease
24 471214 1 • Grease Fitting
25 471240 1 • Vent Fitting
26 5002151 1 Spring, Compression
27 364900 1 Nut, Reel
28 453011 1 Flat Washer, 3/8
29 163892 1 Seal
30 400192 8 Screw, 5/16-18 x 1-1/2” Hex Head
31 446142 4 Lockwasher, 3/8 Heavy
32 304745 1 Washer
33 4247911 1 Coupler, Reel Motor
34 400294 1 Screw, 3/8-24 x 1” Hex Head
35 412503 4 Screw, 3/8-16 x 1-1/4” Square Head
36 2810165 1 Clip, Motor
37 2810166 1 Clip, Motor
