127
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
1000770 1 Rear Roller See 39.1
2 1002224 2 Zerk Bolt
3 446142 2 Lockwasher, 3/8 Heavy
4 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
5 453011 2 Flat Washer, 3/8
6 345510 2 Spacer
7 2000065 1 Casting, Counterweight
8 446130 4 Lockwasher, 1/4 Heavy
9 400110 2 Screw, 1/4-20 x 7/8” Hex Head
10 2810043 1 Shield, Reel
11 403782 1 Screw, 1/4-20 x 3/4” Truss Head
12 443102 4 Nut, 1/4-20 Hex
13 453023 4 Flat Washer, 1/4
14 343616 2 Stud
15 338735 1 Scraper, Rear Roller
16 3005692 2 Knob, Front Roller Adjusting
17 441674 2 Carriage Bolt, 5/16-18 x 1-3/4”
18 400184 2 Screw, 5/16-18 x 3/4” Hex Head
19 445795 4 Locknut, 5/16-18 Hex
20 352737 2 Screw, 1/4-20 x 7/8” Square Head
21 3008438 1 Roller Bracket
22 3008439 1 Roller Bracket
23 403770 2 Screw, 5/16-18 x 3/4” Hex Flange Front Wing Reels Only
24 445795 2 Nut, 5/16-18 Spiralock Flange Front Wing Reels Only
25 452006 1 Flat Washer, 5/16 Front Wing Reels Only
26 3008199 1 Skid, Left Left Front Reel Only
27 3008200 1 Skid, Right Right Front Reel Only
To Next Page
