129
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
2810472 1 Reel, 11 Blade Used on 67986
1 2810471 1 Reel, 9 Blade Used on 67987
2 5002609 1 Frame, 7” Reel
3 4182520 2 • Decal, Danger
4 2811399 1 Bedknife Backing Assembly
455066 AR • Shim
5 503460 1 • Bedknife Standard
6 3009138 13 • Screw, 1/4-20 x 1/2” Flat Head
7 1002811 2 Bearing Housing
8 5002477 2 • Bearing Cup and Cone
9 3006030 2 • Seal
10 471214 2 • Grease Fitting
11 471242 2 • Vent Fitting
12 2500759 2 • Bushing
13 3004734 1 Spring, Compression
14 4166860 2 Coupler
1002532 2 Bedknife Adjuster
15 2000125 1 • Knob
16 3004795 1 • Housing
17 3010470 1 • Spring, Urethane
18 3009892 3 • Spacer, Cup
19 3010472 1 • Rod
20 3010471 1 • Bolt, Special
21 461357 1 • Roll Pin, 1/8 x 5/8”
22 422511 1 • Set Screw, 5/16-18 x 3/8”
23 3005210 2 Retaining Ring
24 365501 2 Bolt, Special
25 434049 8 Screw, 5/16-18 x 2” Socket Head
26 434003 2 Screw, 5/16-18 x 1” Socket Head
27 362643 8 Spacer
28 454017 2 Spring Washer
29 4130092 2 Block, Clamp
30 461419 2 Spring Pin, 1/8 x 3/8”
31 3006028 2 Rod
32 3008601 1 Bracket, Spring
33 445795 2 Nut, 5/16-18 Spiralock Flange
34 400184 2 Screw, 5/16-18 x 3/4” Hex Head
35 446136 6 Lockwasher, 5/16
36 434036 2 Screw, 5/16-18 x 1-1/4” Socket Head
37 455066 2 Washer
38 400182 2 Bolt, 5/16-18 x 5/8 “ Hex Head
39 443106 2 Nut, 5/16-18 Hex
40 3004800 1 Spacer, Reel
