Jacobsen LF570 - Page 131

131
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
445525 2 Palnut, 1/4
2 445795 2 Nut, 5/16-18 Spiralock Flange
3 1002226 2 Zerk Bolt
4 3004738 2 Front Roller Adjuster
5 3005209 1 Shield
6 3009280 1 Scraper, 22” Rear Roller
7 3009281 1 Spring, 22” Rear Roller Torsion
8 343616 2 Stud
9 352737 2 Screw, 1/4-20 x 7/8” Square Head
10 2000135 1 Counter Balance
11 3005692 2 Knob, Roller Adjusting
12 441674 2 Carriage Bolt, 5/16-18 x 1-3/4”
13 443102 4 Nut, 1/4-20 Hex
14 3006022 2 Pin
15 446136 2 Lockwasher, 3/16 Heavy
16 3006021 1 O-Ring
17 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
18 446142 2 Lockwasher, 3/8 Heavy
19 453011 4 Flat Washer, 3/8
20 400108 2 Screw, 1/4-20 x 3/4” Hex Head
21 3006248 1 Deflector
22 3006290 2 Bushing
23 453023 2 Flat Washer, 1/4
24 1003728 1 Rear Roller, 22”
25 1003727 1 • Tube, 22” Roller
26 3008027 1 • Shaft, 22” Roller
27 3005156 2 • Sleeve, Wear
28 3004882 2 • Seal, Grease
29 500534 2 • Bearing, Cup and Cone
30 367029 2 • Locknut, 3/4-16 Stover
