Jacobsen LF570 User Manual

39
> Change from previous revision
7
4
3
10
13
9
11
3008683
3008522
3008521
3008682
105
dB
L
W A
!
4131663
12
4181864
4181862
4181861
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4111408 2 Decal, Bio Fluid
2 3008930 1 Decal, Flash Attach
3 3008683 2 Decal, Backlap Located on Front Axle
4 4181862 1 Decal, Radiator Cap Warning Located on top of Radiator
5 4182386 1 Decal, Jacobsen Emblem
6 4181865 1 Decal, Instruction
7 3008521 1 Decal, Traction Pedal
8 4187681 2 Decal, Jacobsen
9 4181864 Decal, Battery Warning Located on Frame
10 3008682 1 Decal, Tow Valve
11 4181861 1 Decal, Start Fluids
12 4131663 1 Decal, Backlap Located on Radiator Shroud
13 4117468 1 Decal, Noise 105 dB Located on Frame
14 838363 1 Decal, Throttle
15 4239402 2 Decal, LF 550 67978 Only
15 4239403 2 Decal, LF 550 4WD 67979 Only
15 4239404 2 Decal, LF 550 4WD Turbo 67980 Only
15 4239405 2 Decal, LF 570 67981 Only
15 4239406 2 Decal, LF 570 4WD 67982 Only
15 4239407 2 Decal, LF 570 4WD Turbo 67983 Only
16 4199140 1 Decal, Heat Warning
