41
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4266311 1 Hood Assembly Includes Items 8 on Illustration 1.1
2 4130360 AR • Seal, Trim 5 Foot Length, Cut to Size
3 4221520 1 • Foam, Rear
4 822529 2 Hair Pin, 7/16 x 2 x 1/8”
5 446118 4 Lockwasher, #10 Heavy
6 4138359 2 Foam
7 4221420 1 Seal, Left Side Air
8 4221421 1 Seal, Right Side Air
9 3007548 1 Foam, Control Module
10 4212820 1 Backer, Flex Latch Keeper
11 548458 2 Clevis Pin, 1/2 x 1-1/4”
12 800794 4 Screw, 5/16-18 x 3/4” Hex Head
13 800907 4 Nut, 5/16-18 Hex Flange
14 453017 2 Flat Washer, 1/2
15 4212423 1 Latch, Flexible Cover Draw
16 450152 4 Screw, M5-0.8 x 20 mm
17 450332 4 Nut, M5-0.8 Hex
18 3006873 1 Cover, Front Mount
19 3008195 1 Wing Nut, 1/4-20 Steel
20 3009210 1 Foam (Cut To Length)
21 306975 4 Flat Washer
To Next Page
