LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
1004279 1 Floor Pan
2 4218500 1 Seat Pan
3 4217621 1 Support, Seat
4 4210561 1 Adjuster, Double Latching
5 4222229 1 Plug, 2 x 2” Tube
6 400258 9 Screw, 3/8-16 x 3/4” Hex Head
7 441602 4 Carriage Bolt, 5/16-18 x 3/4”
8 445795 12 Nut, 5/16-18 Spiralock Flange
9 446142 9 Lockwasher, 3/8 Heavy
10 452008 4 Flat Washer, 3/8
11 4237303 1 Platform Includes Items 6 - 8, Illustration 1.1
12 3007609 1 • Pad, Left Floorboard
13 3007610 1 • Pad, Right Floorboard
14 4237183 1 • Pad, Left Foot
15 4237182 1 • Pad, Right Foot
16 4241042 1 Grommet
17 4209941 1 Floorboard
18 4123723 1 Latch, Panel
19 4209943 1 Pad, Center Floorboard
20 3005604 2 Receptacle
21 409812 4 Screw, 5/16-18 x 3/4” Thread Cutting
22 4209944 1 Cover, Hydro
23 4237709 2 Stud, 1/4 Turn
24 4203441 1 Suspension Seat Assembly
4210685 1 • Arm Rest Kit R.H. Arm Rest in kit is not used.
25 4210682 1 • • Arm Rest, L.H.
26 4211101 1 • Seat Bottom
27 4210500 1 • Switch, Seat REFERENCE SW-10, See 48.1
28 3003928 1 Pouch, Literature
29 403751 2 Screw, 5/16-18 X 3/4” Serr Washer
30 800943 2 TScrew, #10-16 x 3/4” Plastic
31 831053 4 Spacer, Seat
32 5003769 1 Seat Switch Harness
33 452004 2 Flat Washer, 1/4
34 3005603 2 Retainer, 1/4 Turn Stud
To Next Page
