LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Armrest Assembly
2 4188380 1 Support, Upper Armrest
3 4189843 4 Screw, M6-1 x 65 mm Hex Head
4 4188484 4 Flange, M6 Body Fastener
5 473211 4 Spacer, Black Neoprene
6 4209240 1 Pivot, Lower Armrest Support
7 450193 1 Screw, M8-1.25 x 20 mm Hex Head
8 450411 1 Lockwasher, M8
9 4188569 1 Plunger, Round Nose
10 471216 1 Grease Fitting, 1/4-28 Straight
11 441687 3 Carriage Bolt, 5/16-18 x 3”
12 445795 3 Nut, 5/16-18 Spiralock Flange
13 450334 1 Nut, M16-2 Hex
To Next Page
