49
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4233480 1 Armrest, Upper
2 4168560 1 Armrest, Lower
3 4189540 8 Screw, M4-0.7 x 20 mm Torx
4 4188480 8 Flange, M4 x 4 mm Body
5 4188482 8 Spacer, Black Neoprene
6 4219300 1 Harness, LDU
7 843942 1 • Socket, 12V Accessory Plug
8 N/S 2 ••Screw
9 4131299 1 • Fuse Holder
10 836892 1 • Fuse, 10 Amp
11 4128888 1 Key Switch
4131618 1 • Key
12 N/S 1 • Mounting Nut
13 4192480 1 Washer, 7/8”
14 4150539 1 Horn
15 N/S 1 • Ring Nut
16 1004290 1 Joystick, 1 Axis
17 4189841 8 Flat Washer, 4 mm Stainless Steel
18 450408 4 Lockwasher, 4 mm
19 450321 4 Nut, M4-0.7 Hex
20 4189840 4 Screw, M4-0.7 x 20 mm Pan Head Stainless Steel
21 4174684 1 Switch, Mow
22 4130133 1 Rocker Switch, Momentary Horn Switch
23 4130132 3 Rocker Switch Lights, Brake, Cruise Switches
24 4216682 1 LDU Controller
25 4188840 1 Visor, Armrest
26 409952 4 Screw, M4 x 13 mm Thread Cutting Stainless Steel
27 4168564 1 Hinge, Armrest
28 4201880 4 Screw, #6-32 x 1/2” Flat Head
29 444304 4 Nut, #6-32 Hex
30 4168562 1 Door, Armrest
31 4201867 4 Screw, #6-32 x 3/8” Thread Cutting Stainless Steel
32 4156925 1 Lanyard
33 4201980 4 Screw, #4 x 1/2” Self Threadding
34 4168563 1 Set, Magnetic Catch
35 4189842 4 Spacer
36 4200540 2 Adhesive Mount, Cable Tie
37 402006 1 Screw, #6-32 x 1/2” Slotted Head
38 473142 2 Cable Tie
39 4225220 1 Panel, Plug
40 4244950 1 Shim, LDU Retaining
41 819165 1 Screw, #8-18 x 1/2” Self Drilling
To Next Page
