51
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4218260 1 Pedal, Traction REFERENCE U3, See 48.1
2 4235560 1 Plate, Pedal Support
3 400128 4 Screw, 1/4-20 x 3-1/2” Hex Head
4 453023 4 Flat Washer, 1/4
5 4233220 4 Spacer
6 446130 4 Lockwasher, 1/4 Heavy
7 3003474 1 Grip, Pedal
8 4230160 1 Mount, Arm
9 450399 2 Flat Washer, M6
10 450410 4 Lockwasher, M6
11 450323 2 Nut, M6-1 Hex
12 4225480 1 Plate, Pedal Pivot
13 450171 2 Screw, M6-1 x 20 mm Hex Head
14 400186 2 Screw, 5/16-18 x 7/8” Hex Head
15 445795 2 Nut, 5/16-18 Spiralock Flange
16 4209121 1 Arm, Traction Pedal
17 400410 2 Screw, 1/2-13 x 1-3/4” Hex Head Pedal Stops
18 443118 2 Nut, 1/2-13 Hex
19 3003475 1 Grip, Pedal
20 4234620 1 Tie Strap, Push-On
To Next Page
