53
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4236060 2 Tire, 26.5 x 14-12 4 Ply
2 4210442 2 Rim, 12 x 10.5
3 360111 2 Valve, Inflation
4 4209440 2 Wheel Motor See 42.1
4222844 1 • Seal Kit
4222842 1 • Shaft, Module
4222843 1 • Brake Module
5 4222840 1 • Key, 3/8 x 3/8 x 1”
6 4222841 1 • Nut, 1-20 Slotted Hex
7 4237302 1 Frame Includes Four (4) of Item 10
8 366871 2 • Bushing
9 4208944 1 Front Axle Includes Six (6) of Item 10
10 366870 10 • Bushing
11 452006 1 Flat Washer, 5/16
12 446134 1 Lockwasher, 5/16
13 4209540 2 Hub, Wheel
14 4192520 1 Clamp, Battery
15 400188 1 Screw, 5/16-18 x 1” Hex Head
16 446154 8 Lockwasher, 1/2 Heavy
17 400414 8 Screw, 1/2-13 x 2-1/4” Hex Head
18 353914 12 Wheel Bolt
19 4103061 1 Bracket, Fuel Filter
20 4113047 6 Screw, 5/8-18 x 1-1/2” Hex Head Grade 8 Bolt
21 4192840 1 Battery Tray
22 443128 6 Nut, Hex 5/8-18 UNF
23 452016 6 Flat Washer, 5/8 1.75 x .688 x .1
24 460032 2 Cotter Pin, 1/8 x 1-1/2”
25 445795 4 Nut, 5/16-18 Spiralock Flange
26 441602 3 Bolt, 5/16-18 x 3/4” Carriage
27 4140094 6 Washer .688 x 1.313 x .150 Hard
28 400258 1 Screw, 3/8-16 x 3/4” Hex Head
29 446142 1 Lockwasher, 3/8 Heavy
30 4244422 1 Plug, 3” x 3” Tube
To Next Page
