59
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4219320 2 Tire, 18 x 9.5-8 Treaded 4-Ply S/N 1651 ~ 2499 for all models
1 4236061 2 Tire, 20 x 10-8 Treaded 4-Ply S/N 2500 and Up for all models
2 4236021 2 Rim
3 360111 2 Inflation Valve
4 361648 6 Washer, Thrust
5 361647 2 Bearing, Thrust
6 471214 2 Fitting, Grease
7 461393 2 Pin, Spring 1/4 x 2”
8 117139 1 Steering Axle
9 3010489 4 • Bushing
10 4137137 1 Cylinder, Steering
4137139 1 • Seal Kit
11 443840 2 Nut, 1-12 Hex Jam
12 452022 1 Flat Washer, 1
13 366789 1 Spacer, Axle
14 460064 1 Cotter Pin, 1/4 x 1-1/2”
15 460026 4 Cotter Pin, 1/8 x 3/4”
16 153234 2 Ball Joint
400194 2 • Screw, 5/16-18 x 1-3/4”
444718 2 • Locknut, 5/16-18 Hex
471214 2 • Grease Fitting
17 445666 2 • Nut, 1/2-20 Slotted Hex
18 1002032 1 Ball Joint, Right Hand Thread
19 1002031 1 Ball Joint, Left Hand Thread
471214 2 • Grease Fitting
20 445647 2 • Nut, 3/8-24 Slotted Hex
21 443120 1 Nut, 1/2-20 Hex Right Hand Thread
22 445664 1 Nut, 1/2-20 Hex Left Hand Thread
23 3009378 1 Tie Rod
24 471227 1 45° Grease Fitting
25 460050 2 Cotter Pin, 3/16 x 1-1/4”
26 445710 2 Nut, 1-14 Slotted Hex
27 2812269 1 Spindle, Right
28 2812270 1 Spindle, Left
29 5002910 2 Wheel Hub
30 554329 2 • Seal, Grease
31 500596 2 • Bearing, Cup and Cone
32 545692 2 • Dust Cap
33 354807 8 • Wheel Nut
34 4243304 1 Weight, Rear Axle
35 400188 1 Screw, 5/16-18 x 1” Hex Head
36 452006 1 Flat Washer, 5/16
37 445795 1 Nut, 5/16-18 Spiralock Flange
To Next Page
