Jacobsen LF570 User Manual

61
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4219320 2 Tire, 18 x 9.5-8 Treaded 4-Ply S/N 1651 ~ 2499 for all models
1 4236061 2 Tire, 20 x 10-8 Treaded 4-Ply S/N 2500 and Up for all models
2 4236021 2 Rim
3 360111 2 Inflation Valve
4 361648 6 Washer, Thrust
5 361647 2 Bearing, Thrust
6 471214 2 Fitting, Grease
7 461393 2 Pin, Spring 1/4 x 2”
8 4210701 1 Steering Axle
9 3010489 4 • Bushing
10 4137137 1 Cylinder, Steering
4137139 1 • Seal Kit
11 443840 2 Nut, 1-12 Hex Jam
12 452022 1 Flat Washer, 1
13 366789 1 Spacer, Axle
14 460064 1 Cotter Pin, 1/4 x 1-1/2”
15 460026 2 Cotter Pin, 1/8 x 3/4”
16 4141925 2 Ball Joint
400194 2 • Screw, 5/16-18 x 1-3/4”
444718 2 • Locknut, 5/16-18 Hex
471214 2 • Grease Fitting
17 445672 2 • Nut, 5/8-18 Slotted Hex
18 4121829 1 Ball Joint, Right Hand Thread
19 4121828 1 Ball Joint, Left Hand Thread
4121986 1 • Dust Cover
20 4124204 2 Nut, 9/16-18 Slotted Hex
21 322847 2 Clamp
22 400192 2 Screw, 5/16-18 x 1-1/2”
23 4118210 1 Tie Rod
24 460032 2 Cotter Pin, 1/8 x 1-1/2”
25 2000012 2 Hub, Wheel
26 353914 8 Wheel Bolt
27 367350 2 Washer, Thrust
28 4252432 1 Arm, Left Steering
29 4252433 1 Arm, Right Steering
30 446154 14 Lockwasher, 1/2 Heavy
31 400406 6 Screw, 1/2-13 x 1-1/4” Hex Head
32 2000057 2 Motor Mount
33 4178560 2 Wheel Motor, 2000 Series See 43.1
34 554780 2 • Key
35 554779 2 • Nut
36 400410 8 Screw, 1/2-13 x 1-3/4” Hex Head
37 361451 2 Washer, Thrust
38 471227 1 45° Grease Fitting
39 446136 2 Lockwasher, 5/16 Heavy
40 443106 2 Nut, 5/16-18 Hex
41 460028 2 Cotter Pin, 1/8 x 1”
