65
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
5002918 1 Actuator, Gas Spring
2 5002919 1 Cable, Actuator
3 4253491 1 Tower, Steering
4 4212981 1 Valve, Steering
4197940 1 • Seal Kit
339908 2 • O-Ring, -4 ORFS
339909 3 • O-Ring, -6 ORFS
5 4211400 4 Spacer, Steering Valve
6 4217620 1 Cover, Steering Tower
7 365033 2 Bolt, Shoulder
8 4256510 1 Bracket, Steering Pump
9 2811547 4 Washer
10 4256511 1 Bolt, M6-1 Shoulder
11 450390 3 Flat Washer, M8
12 452418 1 Nut, M6-1 Flange
13 450410 4 Lockwasher, M6
14 447224 1 Lockwasher, 5/8 Internal
15 400216 1 Screw, 5/16-18 x 2-3/4” Hex Head
16 445795 9 Nut, 5/16-18 Spiralock Flange
17 416911 2 Screw, #10-24 x 1/2” Thread Cutting
18 404016 6 Screw, 1/4-20 x 5/8” Truss Head
19 548804 2 Nut, 3/8-16 Hex Flange
20 441677 2 Carriage Bolt, 5/16-18 x 1-1/2”
21 441614 4 Carriage Bolt, 5/16-18 x 1”
22 2811364 1 Steering Wheel
23 2811365 1 • Cap, Steering Wheel
24 445245 6 Tinnerman Nut
25 450411 4 Lockwasher, M8
26 4212980 1 Shaft, Steering
27 4201840 1 • Shaft Seal
28 443828 1 • Nut, 5/8-18 Hex
29 64205-054 4 Screw, M8-1.25 x 130 mm Hex Head
30 450168 4 Screw, M6-1 x 12 mm Hex Head
31 4255270 2 Flanged Bearing
32 4247312 2 Spacer
To Next Page
