71
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
3001965 1 Air Filter
5000919 1 • Air Cleaner Element
5000920 1 • Cover
5000921 1 • Valve
2 3001388 1 Bracket, Air Filter
> 3 4138381 1 Shroud, Rear Frame
4 4121722 1 Bracket, Air Cleaner Mounting
5 4234763 1 Shroud, Radiator Fan Includes Decal 4131663
6 557367 1 Recovery Tank
7 557374 1 Tank, Stay
8 4180020 1 Radiator / Hydraulic Oil Cooler Includes Decal 365956
550863 1 • Radiator Cap
9 4121686 1 Hose, Air Cleaner Intake
10 4121684 1 Hose, Radiator Outlet
11 554748 1 Hose, Radiator Overflow, Bulk
12 4169424 1 Hose, Air Cleaner to Pipe
13 4183402 1 Hose, Radiator Inlet
14 365398 1 Indicator, Air Cleaner
15 4169423 1 Hose, Pipe to Turbo Intake
16 445796 4 Nut, 3/8-16 Spiralock Flange
17 400182 2 Screw, 5/16-18 x 5/8” Hex Head
18 445640 2 Nut, 3/8-16 Steel Wing
19 3002195 1 Elbow, 90°
20 445795 2 Nut, 5/16-18 Spiralock Flange
21 359615 2 Clamp, Hose
22 326112 AR Clamp, Hose
23 4168440 1 Pipe, Hose Connection Included with Engine
24 367458 2 Clamp, Hose
25 48540-01 1 Clamp, Hose
26 452008 12 Flat Washer, 3/8
27 362535 2 Screw, M6-1 x 16 mm Hex Head
28 400264 8 Screw, 3/8-16 x 1-1/4 Hex Head
29 450410 2 Lockwasher, M6
30 446140 8 Lockwasher, 3/8
31 450399 2 Flatwasher, M6
32 830930 2 Clamp, Hose
33 450323 2 Nut, M6-1 Hex
34 3006434 1 Switch, Backlap REFERENCE SW-4, See 48.1
35 345671 1 Clamp, Overflow Hose
36 4201661 1 Hose, 7/16” Fuel
37 4234240 1 Bracket, Recovery Tank
> 38 4266292 AR Seal, Trim 10 Foot Length, Cut to 72”
To Next Page
