75
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4162400 1 Engine, Kubota V1505-E3B LF 550, LF 570
1
4162421 1 Engine, Kubota V1505-T-E3B LF 550 Turbo, LF 570 Turbo
2 366879 3 Isolator, Engine
3 1003239 1 Front Engine Mount
4 1003260 1 Left Side Engine Mount
5 1003261 1 Right Side Engine Mount
6 4233120 1 Cable, Throttle See 12.1 for other end of cable
7 558021 2 • Clip
8 5003460 1 • Wire Stop
9 403740 1 • • Screw, #8-32 x 1/2” Hex Head
10 3006797 1 Bracket, Cable Mounting
11 554988 1 Pivot, Throttle Cable
12 400108 1 Screw, 1/4-20 x 3/4” Hex Head
13 445794 1 Nut, 1/4-20 Spiralock Flange
14 444708 1 Locknut, 1/4-20 Center
15 452006 2 Flat Washer, 5/16
16 363485 12 Lockwasher, M10 Heavy
17 366884 9 Screw, M10-1.25 x 20mm Hex Head
18 362263 2 Screw, M10-1.25 x 25mm Hex Head
19 361695 2 Screw, M801.25 x 110mm Hex Head
20 400188 8 Screw, 5/16-18 x 1” Hex Head
21 400272 3 Screw, 3/8-16 x 2-1/4” Hex Head
22 444762 3 Locknut, 3/8-16 Center
23 446136 2 Lockwasher, 5/16 Heavy
24 445795 7 Nut, 5/16-18 Spiralock Flange
25 364501 1 Temperature Sender REFERENCE R-2, See 48.1
26 453023 1 Flat Washer, 1/4
27 363586 1 Screw, M8-1.25 x 20 mm Hex Head Replaces 361898
28 446134 1 Lockwasher, 5/16
29 3010575 1 Spacer, Isolator
30 367031 3 Washer, Isolator
31 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
32 409811 1 Screw, 5/16-18 x 3/4” Thread Cutting
33 2810424 1 Cable, Ground
34 447214 2 Lockwasher, 5/16 Internal Tooth
To Next Page
