77
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4209500 1 Pump, Traction
5003034 1 • Seal Kit
5003433 1 • Shaft Seal Kit
5003434 2 • 3625 psi System Relief Kit
4224120 1 • Charge Relief Kit
4224121 1 • O-Ring, Charge Relief
4224140 1 • EDC Kit
4224180 1 • O-Ring, EDC
4224181 2 • O-Ring, EDC Screw
4229220 1 • EDC Connector, Female Socket
4229221 2 • Pin, Male
4229222 2 • Seal, Wire
2 1002154 1 Pump, 3 Section Gear
5003036 1 • Seal Kit
3 1002854 1 Driveshaft
554663 2 • Cross and Bearing Kit
4 446136 6 Lockwasher, 5/16 Heavy
5 446154 2 Lockwasher, 1/2 Heavy
6 443118 2 Nut, 1/2-13 Hex
7 363485 3 Lockwasher, M10 Heavy
8 362263 3 Screw, M10-1.25 x 20mm Hex Head
9 444762 2 Locknut, 3/8-16 Center
10 553020 1 Gasket, Exhaust
11 348856 1 Clamp, Exhaust
12 3007889 1 Sleeve Insulating
13 400266 2 Screw, 3/8-16 x 1-1/2” Hex Head
14 400410 2 Screw, 1/2-13 x 1-3/4” Hex Head
15 400264 2 Screw, 3/8-16 x 1-1/4” hex Head
16 446142 2 Lockwasher, 3/8 Heavy
17 362743 1 O-Ring Seal
18 1004653 1 Muffler LF 550, LF 570
18 4181902 1 Muffler LF 550 Turbo, LF 570 Turbo
19 1004598 1 Tailpipe
20 363586 6 Screw, M8-1.25 x 20mm Hex Head
21 452006 2 Flat Washer, 5/16
22 363485 2 Lockwasher, M10 Heavy
23 366884 2 Bolt, M10-1.25 x 25mm Hex Head
To Next Page
