81
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
132647 1 Valve, Shut Off
2 3001279 1 Switch, Float REFERENCE SW-9, See 48.1
3 3002397 1 Plug, Magnetic
339899 1 • O-Ring
4 4237504 1 Fuel Tank
5 3005871 1 Hydraulic Tank
6 3005872 1 Shell, Tank Cover
7 3006243 2 Plate, Tank Mounting
8 3007558 2 Clamp, Double Tube
9 3006332 1 Breather Filter
10 400112 1 Screw, 1/4-20 x 1” Hex Head
11 445784 1 Nut, 1/4-20 Hex Whizlock
12 4237622 1 Fuel Tank Cap with Gauge
13 554748 1 Fuel Line, 5/16” I.D. Cut to 72 Inches
14 554748 1 Fuel Line, 5/16” I.D. Cut to 18 Inches
15 361117 3 Bushing, Fuel Tank
16 361748 1 Valve, Overflow
17 554752 1 Fuel Line, 3/16 I.D. Cut to 70 Inches
18 48540-01 6 Clamp, Hose
19 403769 14 Screw, 1/4-20 x 1/2” Hex Flange
20 2810702 1 Valve, Needle
21 404016 5 Screw, 1/4-20 x 5/8” Truss Head
22 473142 2 Cable Tie4 .19 x 14-16 UV Black
23 5003374 1 Gasket, Fuel
24 403910 5 Screw, #10-24 x 1/2” Truss Head
25 4238043 1 Plate, Fuel Block-Off
26 446118 5 Lockwasher, #10
27 403908 6 Screw, #10-24 x 3/8” Truss Head
28 4222560 1 Plate, Blanking
To Next Page
