> Change from previous revision

LF 570

Item Part No. Qty. Description Serial Numbers/Notes

123015 1 Charge Filter See 24.1 and 27.1

556417 1 • Head

2811255 1 • Oil Filter Cartridge

556419 1 • Charge Pressure Switch REFERENCE SW-1, See 48.1

2 132704 1 Return Filter See 25.1

557772 1 • Oil Filter Cartridge

3 3007290 1 Bracket, Filter

4 409811 4 Screw, 5/16-18 x 5/8” Thread Cutting

5 446130 8 Lockwasher, 1/4 Heavy

6 446142 8 Lockwasher, 3/8 Heavy

7 400258 8 Screw, 3/8-16 x 3/4” Hex Head

8 400108 4 Screw, 1/4-20 x 3/4” Hex Head

9 4195081 1 Lift Valve See 44.1, 28.1, and 29.1

10 4195041 1 Reel Valve, Front See 41.1 and 26.1

11 4195041 1 Reel Valve, Rear See 41.1 and 27.1

12 4211880 1 Valve, Brake See 24.1

13 4209880 1 Valve, 4WD See 23.1

14 400106 4 Screw, 1/4-20 x 5/8” Hex Head

15 4244403 1 Bracket, Clamp
