LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4260170 1 Pump, Traction See 17.2
2 339999 2 Fitting, 16-16 Straight
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
3 4251542 1 Tube, Forward Traction Traction Pump Port A
339913 2 • O-Ring, -16 ORFS
4 4251543 2 Hose, Upper Traction Motor Port
339912 1 • O-Ring, -12 ORFS
5 339993 4 Fitting, 12-10 Straight
339912 1 • O-Ring, -12 ORFS
339899 1 • O-Ring, -10 ORB
6 4228801 2 Motor, Front Traction See 7.1
7 4241541 2 Hose, Lower Traction Motor Port
339912 2 • O-Ring, -12 ORFS
8 4213420 1 Tube, 4WD Reverse Traction
9 339975 2 Fitting, 4-8 Straight
339908 1 • O-Ring, -4 ORFS
339898 1 • O-Ring, -8 ORB
10 4251544 2 Hose, Front Traction Motor Drain
339908 1 • O-Ring, -4 ORFS
11 339960 1 Nut, -4 Bulkhead Fitting
12 340214 1 Tee, 4-4-4 Bulkhead Run
339908 3 • O-Ring, -4 ORFS
13 4212141 1 Tube, Front Motor Drain
14 4215400 1 Tube, Oil Cooler Return See 25.1
339908 2 • O-Ring, -4 ORFS
339909 1 • O-Ring, -6 ORFS
15 4251624 1 Tube, Left 4WD Forward Traction
16 4251621 1 Tube, Right 4WD Forward Traction
17 365566 2 Hose Clamp Upper traction hoses to axle
18 409811 2 Screw, 5/16-18 x 5/8” Thread Cutting
19 4251531 4 Tube, Front Motor
20 4251532 1 Tube, Left Front Motor Drain
21 4251547 1 Tube, RIght Front Motor Drain
22 367028 2 Clamp, Tube
23 4244342 2 Clamp, Double Tube
To Next Page
