Jacobsen LF570 - Page 95

95
> Change from previous revision
LF 570
Item Part No. Qty. Description Serial Numbers/Notes
1
4209283 1 Tube, Left 4WD Forward Traction 4WD Valve Port LF, See 22.1
2 4210280 1 Tube, Right 4WD Forward Traction 4WD Valve Port RF, See 22.1
3 339994 2 Fitting, 12-12 Straight
339912 1 • O-Ring, -12 ORFS
339900 1 • O-Ring, -12 ORB
4 340034 4 Fitting, 10-12 45°
339911 1 • O-Ring, -10 ORFS
339900 1 • O-Ring, -12 ORB
●
5 4137607 1 Hose, 4WD Valve to Left Rear Motor
4WD Valve Port LRF
Left Motor Port B
●
6 4137608 1 Hose, 4WD Valve to Right Rear Motor
4WD Valve Port RRF
Right Motor Port A
7 339989 2 Fitting, 10-10 Straight
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
8 4137607 1 Hose, Right Rear Motor to 4WD Valve
4WD Valve Port RRR
Right Motor Port B
9 4137608 1 Hose, Left Rear Motor to 4WD Valve
4WD Valve Port LRR
Left Motor Port A
10 4209880 1 Valve, 4WD See 19.1
11 339999 1 Fitting, 16-16 Straight
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
12 4213420 1 Tube, 4WD Reverse Traction 4WD Valve Port REV, See 22.1
13 339979 1 Fitting, 6-6 Straight
339909 1 • O-Ring, -6 ORFS
339897 1 • O-Ring, -6 ORB
14 4209281 1 Tube, 4WD Valve Drain 4WD Valve Port DRN
15 340055 1 Fitting, 4-4 90°
339908 1 • O-Ring, -4 ORFS
339896 1 • O-Ring, -4 ORB
● 16 4227040 2 Hose, Rear Motor Case Drain
17 340142 1 Tee, 4-4-4 Swivel Branch
339908 2 • O-Ring, -4 ORFS
18 4215400 1 Tube, Oil Cooler Return See 25.1
339908 2 • O-Ring, -4 ORFS
339909 1 • O-Ring, -6 ORFS
19 4178560 2 Motor, Rear Traction See 10.1
20 340070 2 Fitting, 10-10 90°
339911 1 • O-Ring, -10 ORFS
339899 1 • O-Ring, -10 ORB
21 340377 2 Fitting, -10 Swivel
339911 1 • O-Ring, -10 ORFS
● Included in hose bundle 4244543
