QUALITY OF CUT 5
27
5.8 MISMATCHED CUTTING UNITS ______________________________________________
NOTE: Arrow indicates direction of travel.
Mismatched decks is a pattern of varying cutting heights,
resulting in a stepped cut appearance, usually due to
mismatched HOC (height-of-cut) adjustment from one
deck to another.
Probable Cause Remedy
HOC inconsistent from one deck to another. Check/adjust HOC on decks to same height. (Refer to Parts &
Maintenance Manual.)
Difference in blade speeds. Check operation of rotary cutting motor(s) and repair/replace as
necessary.
Difference in deck ride height side to side. Check/adjust tire inflation pressure. (Refer to Parts & Maintenance
Manual.)
Decks not level. Level decks. (Refer to Parts & Maintenance Manual.)
Deck rake not set. Adjust decks so that front of blade is 1/8 in. (1.25 mm) lower than
rear of blade. (Refer to Parts & Maintenance Manual.)
