CONTROLS 2
en-11
T3. Charge Pressure Light stays on
after starting engine or comes on
during operation. Indicates low
charge pressure in traction
system.
Stop mower immediately, lower implements and shut off engine! Check
hydraulic oil level in main tank. Visually inspect mower for obvious signs of leaks
around connections, hoses and tubes. Tow or trailer mower back to service area.
Never operate mower with charge pressure light on, severe damage to hydraulic
system components can result.
CAUTION: Hydraulic system is under pressure. Turn engine off and allow
oil to cool before checking oil level or adding oil to tank.
T4. Hydraulic Return Oil Filter -
Oil filter warning light comes on.
Return mower to a service area as soon as possible. Change hydraulic
return oil filter.
Continued on next page
T5. Hydraulic Oil Temperature
Horn sounds. Hydraulic oil
temperature high.
Stop mower, disengage drives and lower implements. Run engine at low
idle for a few minutes until light goes off. If light remains on, shut off engine and
allow hydraulic system to cool. Remove debris such as leaves and grass
clippings that may be restricting air flow through rear screen on hood and area
between radiator and oil cooler. If hydraulics continues to run hot, return mower
to service area.
CAUTION: Hydraulic system is under pressure. Turn engine off and allow
oil to cool before checking oil level or adding oil to tank.
T6. Hydraulic Charge Oil Filter -
Oil filter warning light comes on.
Return mower to a service area as soon as possible. Change hydraulic
charge oil filter.
T7. Air Filter - Air filter warning light
comes on.
Return mower to a service area as soon as possible. Change air filter.
T8. Glow Plug - Glow plug light
comes on.
Glow plug switch depressed. Do not energize glow plugs with engine running.
Alert Action
