Jacobsen R311T-T4F - Specifications Overview; Engine and Mower Specifications

SPECIFICATIONS 4
10
4Specifications
4.1 ENGINE SPECIFICATIONS __________________________________________________
R311T
Make Kubota
Model V2403-CR-T-E4B
Type Four cycle, liquid cooled, Diesel
Number of Cylinders 4
Bore and Stroke 3.43 in. (8.7 cm) x 4.03 in. (10.24 cm)
Total Displacement
148.5 in
3
(2.434 l)
Combustion System Direct Injection
Intake System Turbocharged
Gross Intermittent Power 65.2hp (48.6 kW)@2700 rpm
Torque 146.4 ft.Lb. (198.5 Nm) @1600 rpm
Maximum Speed 2950 ± 50 rpm (No Load)
Low Idle 1000 ± 50 rpm (No Load)
Rotation Counter-clockwise viewed at flywheel
Fuel #2 ultra-low sulfur Diesel fuel
Injection Pump Bosch MD type mini pump
Engine Oil (API Class) CJ-4
Oil Pan Capacity 2.51 gallons (9.5 l)
Starter 12 Volt, 2 kW
Alternator 12 Volt, 45 Amp
Dry Weight 514 lb. (233 kg)
Dimensions
(Length x Width x Height)
34.2 x 20.4 x 28.9 in.
(86.9 x 51.7 x 73.5 cm)
Emission Regulation Tier 4 Final/ Stage IIIB
