en-63
9.14 SPEED LIMITER
The transport and mow speeds are factory set and
should not need altering.
NOTE: Textron Turf Care cannot be held responsible
for loss of performance or machine damage if these
speeds are adjusted outside the speeds shown in the
machine specification.
9.15 SEAT (Milsco CE-200)
The seat can be adjusted for operator's weight and
leg reach to provide a comfortable position for
operating the machine.
A. ADJUSTMENT FOR OPERATOR WEIGHT
To Adjust:
Whilst sitting on the seat push knob A downwards
and allow it to slid back upwards until a comfortable
amount of suspension is found.
B. FORE AND AFT ADJUSTMENT
To Adjust:
The position of the adjusting lever is on the left hand
side of the seat below the seat cushion (B). By moving
the lever upwards, the seat can be slid backwards
and forwards. When in the desired position release
the lever to locate in one of the pre set positions.
C. BACK REST ADJUSTMENT
The back rest has three preset positions
To Adjust:
Move the lever upwards and slid the seat cushion
backwards and forwards to obtain a comfortable back
rest position.
NOTE: The seat is fitted with a microswitch to sense
operator presence. When the machine is fitted with
a ROPS frame or cab a lap belt is fitted and should
be worn at all times
WARNING
The Operator Weight must be set to the actual
weight of the Operator. Safety Systems will be
compromised if this is not done.
ADJUSTMENTS 9
