TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
008008460 5 Nut, M14-1.5 x 34 mm Wheel Torque to 112 Nm (83 ft. lb.)
2 450020281 1 Nut, 1/2-20 Thin Hex
3 002143004 4 Bush, 10 x 12 x 10
4 008006260 1 Nut, 1-20 Wheel Motor Torque to 400 Nm (295 ft. lb.)
5 008145256 1 Rod End, 1/2-20
6 4183560 1 Screw, M6-1 x 20 mm Hex Socket
7 4192800 1 Hub, Wheel Nut
8 4244289 1 Cylinder, Steering See 36.1 for Service Parts
9 4273470 6 AV Washer - 13 x 19.5 x 2.5
10 4366566 1 Bracket, Journal Mounting
11 4379491 1 Wheel Hub
12 4379887 1
Motor, 28.7 in
3
Wheel
See 45.1 for Service Parts
13 679269 1 3WD Wheel Yoke
14 450020281 1 Nut, 1/2-20 Thin Hex
15 450056 4 Screw, M12-1.75 x 80 mm Hex Head
16 450214 4 Screw, M10-1.5 x 30 mm Hex Head
17 450391 4 Washer, M10 x 21 x 2.2
18 450392 2 Washer, M12 x 24 x 2.7
19 450413 4 Lock Washer, M12 x 17.9 x 2.5
20 450455 4 Nut, M12-1.75 Hex Flange
Grade 10
Torque to 120 Nm (88 lb. ft.)
21 800724 1 Hex Head Screw, 2.1/2 Torque to 140 Nm (103.3 lb. ft.)
22 4399226 5 Stud, M14-1.5 x 50 mm
23 MBC5942 1 Journal
24 MBC5959A 4 Bolt, 1/2-20 x 12mm
4375486 1 Wheel and Tire Assembly Treaded Tire Option
25 4375487 1 • Tire, 20 x 10-10 4 Ply Grassmaster Treaded Tire Option
26 4220940 1 • Tubeless Tire Valve
27 4375488 1 • Wheel, 10 x 8.5
4375489 1 Wheel and Tire Assembly Smooth Tire Option
28 4233900 1 • Tire, 20 x 10 - 2 Ply OTR Smooth Tire Option
29 4220940 1 • Tubeless Tire Valve
30 4375488 1 • Wheel, 10 x 8.5
31 450412 4 Lock Washer, M10 x 15.9 x 2.5
32 554780 1 Key
33 680151 1 Cotter Pin, 1/8” x 2”
To Next Page
