Jacobsen TR330 User Manual

39
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
450620 4 Screw, M6-1 x 20 mm Countersunk
2 450214 9 Screw, M10-1.5 x 25 mm Hex Head
3 450412 9 Lock Washer, M10 x 15.9 x 2.5
4 001599264 10 Washer, 25/64 x 1 x .106
5 4312406 2 Hinge, Dies Cast Zinc
6 4363146 1 Bracket, Hood Mount
673809 1 Hydraulic Tank Assembly
7 673813 1 • Hydraulic Tank
8 4370752 1 • Breather, Filter
9 4394849 1 • Strainer, Suction Torque to 40 Nm (29.5 ft. lbs.)
339904 1 • • O-Ring, -32 ORB
10 671857 1 Lanyard, Hood
11 669840 4 Pop Rivet, 4.8 x 14
12 2198112 1 Draw Latch
13 N/S 1 • Latch, Keeper
14 4356728 1 Hood, Engine
15 450387 14 Washer, M4 x 9 x 0.9
16 450520 4 Screw, M4-0.7 x 20 mm Pan Head
17 452717 10 Nut, M4-0.7 Hex Nyloc
18 MBG6720 1 Bracket, Hood Latch
19 4334427 4 Screw, M6-1 x 20 mm Button Head
20 450452 4 Nut, M6-1 Hex Flange
21 4111408 1 Decal, Bio-Fluid
22 4164860 1 Decal, Hydraulic Fluid
23 450454 1 Nut, M10-1.5 Hex Flange
24 450477 1 Screw, M10-1.5 x 20 mm Hex Flange
25 4397106 2 Decal, Jacobsen
26 4400049 2 Decal, TR330
27 4389850 1 Cargo Net, Hood
28 450519 6 Screw, M4-0.7 x 16 mm Pan Head
