47
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
4354951 1 Tank, Hydraulic
2
4394849 1 • Strainer, Suction
339904 1 • • O-Ring, -32 ORB
3 340001 1 Fitting, -20 ORFS x -20 ORB Torque to 190 Nm (140 ft. lbs.)
339914 1 • O-Ring, -20 ORFS
339902 1 • O-Ring, -20 ORB
4 4391256 1 Hose, Tank Suction Line
5 339999 1 Fitting, 90° 16-16 Straight Thread
339913 1 • O-Ring, -16 ORFS
339901 1 • O-Ring, -16 ORB
6 340030 1 Fitting, 45° 8-10 Straight Thread
339910 1 • O-Ring, -8 ORFS
339899 1 • O-Ring, -10 ORB
7 4371126 1 Hose, Pump to Steering Valve Steering Valve Port P
4396209 1 Bundle, 3WD Steering Hose
8 4391206 1 • Hose, Steering Valve to Cylinder Valve Port L, Cylinder Left Port
9 4391206 1 • Hose, Cylinder to Steering Valve Cylinder Right Port, Valve Port R
10 4400027 1 Tube, Pressure Line Lift Valve
11 4399271 1 Tube, Return Line - Steering Valve
339909 1 • O-Ring, -6 ORFS
12 340062 1 Fitting, 90° 6-8 Straight Thread
339909 1 • O-Ring, -6 ORFS
339898 1 • O-Ring, -8 ORB
13 4169021 1 Weight Transfer And Lift Valve See 37.1 for Service Parts
14 4393849 1 Valve, Steering See 43.1 for Service Parts
15 339972 2 Fitting, -4 ORFS x -4 ORB Straight
339908 1 • O-Ring, -4 ORFS
339896 1 • O-Ring, -4 ORB
16 4244289 1 Steering Cylinder See 39.1 for Service Parts
17 4134071
1
Pump, Cutter And Steering See 43.1 for Service Parts
To Next Page
