Jacobsen TR330 User Manual

71
> Change from previous revision
TR330
Item Part No. Qty. Description Serial Numbers/Notes
1
3006233 2 Washer, ISOL
2 345510 1 Spacer, Reel Unit Mounting
3 400260 3 Screw, 3/8-16 x .875 Hex Head
4 400266 1 Screw, 3/8-16 x 1.50 Hex Head
5 403751 4 Screw, 5/1-18 x .750
6 4371652 2 Casting, Catcher Ductile Iron
7 4371653 1 Latch
8 4371654 1 Catch
9 4371655 1 Spring, LS
10 4371656 1 Spring, RS
11 684322 2 Pin, Catcher
12 4388786 1 Centre Grass Catcher, 26”
13 4397227 1 Grass Catcher Plate-LH
14 4398526 1 Grass Catcher Plate-RH
15 445806 2 Nut, 3/8-16 Hex Nylon
16 452006 2 Flat Washer, 5/16 x .875 x .078
17 455012 1 Washer, 3/4 OD
18 3007844 2 Catcher, 26”
19 4139527 1 Weldment, LH Outer
20 4139528 1 Weldment, LH Inner
21 4139529 1 Weldment, RH Outer
22 4139530 1 Weldment, RH Inner
23 450002 8 Hex Bolt, M6 x 35
24 450389 8 Washer, M6 x 12.5 x 1.8
25 450410 8 Washer, M6
26 002952722 4 End Cap, 22 x 22 x 22
